查看大图 生产厂家：S上海申安灭菌器 参考价格：28000 产品型号 LDZH-200L 适用范围 本款立式高压蒸汽灭菌器，源自于上海申安的专业技术与创新，是一款集成先进科技于传统设备设计之中，符合国家对压力容器设计与制作的严格规定，并获得了食药监产品注册证和消毒产品卫生许可证。其结构先进可靠，操作简便且功能全面，在安全性上配备了多重保障系统，如超压自泄、断水保护、超温自控等装置。本机采用微机自动处理技术，以实现精确控制和智能化管理。液晶显示窗提供清晰的运行状态展示，让用户轻松监控整个灭菌过程。此外，全不锈钢材质构建，耐腐蚀且易于清洁，其主要部件均经过精细加工以确保长期稳定性能。该系列设备广受医疗机构、大专院校、食品及生物科研单位青睐，因为它们能有效消毒并达到医用手术级标准，对各种器械、敷料、药液及食品等进行高效杀菌。
灭菌原理 这款立式高压蒸汽灭菌器运用湿热杀死微生物的科学原理进行设计。通过重力置换法，将蒸汽从上向下进入到物品中，而排出冷空气则是从下方排气孔排出的，这样冷空气被替换为饱和蒸汽，并利用蒸汽释放潜热，使得物品达到充分滅菌。湿热滅菌方式具有显著优势，因为它可以增加微生物蛋白质含水量，从而加速在温度作用下的死亡过程。
企业标准 Strictly adhering to the standards set by Q31/C006-2016《立式压力蒸汽灭菌器》, this device has earned its place in the market. Moreover, it holds a medical equipment product registration number of沪食药监械（准）字2013第2571467号.
功能简介 Equipped with cutting-edge features such as hand-wheel opening mechanism, automatic control of sterilization cycles, safety lock interaction system, and LED digital display for running status. This device boasts an impressive range of functions including setting temperatures from 50℃ to 126℃ and cycle times up to 99 hours. Its durable design ensures seamless performance even under high pressure conditions.
技术参数 With an effective capacity of 200L and weighing approximately 200Kg, this unit operates on a power supply of 380V with a total power consumption of 6Kw. Constructed from premium-grade stainless steel material with a thickness of just over 4mm for added strength and durability. The compact size allows for easy placement within various settings while ensuring optimal performance.
主要部件 A comprehensive list detailing each component's specifications is provided below:
Pressure temperature switch / High & Low pressure: Each one
Foot pedal switch /250V -15A: One
Solid-state relay /440V -40A: One
Electric heating tube /2Kw: Three
Spring-loaded safety valve /0.217-0.24Mpa: One
Pressure gauge /1/16 level: One
7.Opening valve/0.Mpa :One
8.Silicone seal ring :One
9.Control panel :One
10.Fuse/380V -16A :Three
11.Electric solenoid valve/220V :Two
As the leading manufacturer specializing in Shanghai Shen'an's LDZH-200L (non-medical model) stand-up steam sterilizer units since years ago, we assure quality that exceeds expectations if you seek more information about pricing or other details regarding these units please feel free to contact us at any time!
