探索电厂变压器温度的神秘：BWY-803AA(TH)解密

电厂变压器温度BWY-803AA(TH)

BWY-803系列变压器用压力式温度，主要是为了测量和控制大、中型油浸式变压器而设计的产品。本系列温控器是根据JB/T6302-92《变压器用压力式温度》标准，在BWY-802、803型温度的基础上研制开发的新一代产品。可分别用于变压器冷却系统的启动、关闭和信号报警及超温跳闸等。为了能使中心机房获得实时温度信号，BWY系列温度可配套数显temperature仪,同步显示variancepresser油温,并可以与计算机联网。

工作原理

BWY-803系列 温控器应用“热胀冷缩原理,在密闭系统内充满了感温介质。当感温头放入被测物质中，而物质的temperature发生变化时，由于填充介质的热胀冷缩，感温头内部的填充介质发生了体积变化，这体积变化通过毛细管传递至表头内部的弹性元件，使之发生了相应位移，该位移量经放大机构放大后，便可直接指示被测物质’s temperature。同时，位移量也传递给了转动开关’触发开关闭合，输出信号。从而达到控制variancepresser oil temperature、report alarm、trip breaker等功能。

BWY(WTYK)-802A、803A、804type variancepresser temperature indicator采用复合传感技术，即instrumentation warm pack推动elastic element's同时，可同步output Pt100 thermoelectric resistance signal，此signal可远transmit到hundred of meters外of control room通过XMT series digital thermometer instrument synchronize display and control variancepresser oil temperature. Also can through XMT series digital thermometer instrument将Pt100 thermoelectric resistance signal转换成与computer network直流standard signal（0～5V、1～5V、4～20mA）output. Adopt external wiring box for easy user connection.

主要technical parameters：

1.BWY-803A（TH）voltage regulator ⑴ Working conditions: environment -40 to 55℃；relative humidity <95% ⑵ Measurement range: 0~100℃; accuracy level: 1.5 levels

Control switch: three groups adjustable switches; setting error ±3℃; switching difference 6±2℃ Standard settings point K1=55℃；K2=65℃ (without); K3=80℃ Connection power AC220V；50Hz; DC220V/50W

Output signal available PT100 thermocouple voltage output or current output

Note: The above technical parameters are based on the original product data provided by the manufacturer.

The BWY-WTYK Series Voltage Regulator is a new generation of products developed based on JB/T6302 standards in accordance with the voltage regulation requirements of large-scale transformers. This device uses advanced technology and has undergone rigorous testing to ensure its reliability and performance.

In order to meet different customer needs, our team has designed this product with a variety of features that make it easy to use and install while ensuring safety during operation.

We hope that you will find this information helpful in your search for high-quality voltage regulators suitable for your specific application needs.

Thank you for considering our BW-YWT Series Voltage Regulator!
